If you connect two identical storage batteries together in parallel, and place them in a circuit, the combination will provide

Question

BlackTom AI · Accepted Answer

Connecting two identical batteries in parallel keeps the terminal voltage the same but adds their stored charge (capacity). Key concepts: battery voltage is determined by its electrochemical cell potential; capacity (charge or ampere-hours) is an additive quantity when cells share the same voltage; internal resistances in parallel combine like resistors.

1) Relevant knowledge points
- Voltage of identical ideal sources in parallel remains the same as each source (open-circuit voltage does not add in parallel; it adds in series).
- Charge/capacity (measured in coulombs or ampere‑hours) adds when cells are paralleled because both contribute current to the load.
- Internal resistance r of identical batteries in parallel becomes r_eq = r/2, increasing possible output current but not the open-circuit voltage.

2) Step-by-step reasoning
- Let each battery have voltage V and capacity C (in ampere‑hours, Ah).
- Parallel connection: positive terminals joined, negative terminals joined → same potential difference V across the combined terminals.
- Capacities add: total capacity = C_total = C1 + C2 = C + C = 2C.
- Internal resistances r in parallel: r_eq = (r·r)/(r + r) = r/2, so the combination can deliver more current for a given load, but the nominal terminal voltage remains V.

3) Example calculation (intermediate steps)
- Suppose each battery is 1.5 V and 2.0 Ah (2.0 A for 1 hour).
- Combined parallel battery: voltage = 1.5 V (unchanged).
- Combined capacity = 2.0 Ah + 2.0 Ah = 4.0 Ah.
- In coulombs: each has Q = 2.0 A·3600 s = 7200 C; combined Q_total = 2·7200 = 14400 C.

4) Why the correct answer is correct
- Parallel adds capacity (charge) but does not raise cell potential; therefore you get the same voltage and twice the total charge.

5) Why other choices are incorrect
- "Twice the voltage..." options describe series connection, not parallel.
- "Half the voltage..." is incorrect for parallel (would be if something were divided, but not here).
- "Twice the voltage and the same total charge" mixes series voltage addition with incorrect capacity behavior for that configuration.

6) Conclusion
The correct choice is: the same voltage and twice the total charge that one battery would. This matches the provided answer.
