You may find it useful to watch the video below before attempting this question or viewing it on theBox here: .
You use a meter ruler to measure the length of a metal rod. Select the most suitable category for the uncertainty in this measurement.

Question

BlackTom AI · Accepted Answer

The resolution of the metre ruler (its smallest division) sets the typical random uncertainty in a single length reading: you cannot read between the smallest marks precisely, so the measured value has a scatter of about ±half a division.

1) Relevant knowledge points and concepts
- Random uncertainty (also called statistical) arises from unpredictable variations between repeated measurements (e.g., slightly different eye position, small shifts of the rod, reading fluctuations).
- Systematic uncertainty is a reproducible bias that shifts all readings in the same direction (e.g., a zero-offset on the ruler, a calibration error, thermal expansion of the ruler).
- For a scale with smallest division d (1 mm here), a common estimate of absolute reading uncertainty is ±d/2. If the distribution of possible true values within that half-division is assumed uniform, the standard uncertainty is (d/2)/√3.

2) Step-by-step reasoning
- You use a metre ruler with divisions of 1 mm to read the rod length.
- Different readings taken (or different observers) will scatter by about ±0.5 mm because you cannot resolve smaller increments reliably — this is random variation in readings.
- Systematic effects (zero error, a bent ruler, or wrong calibration) could exist but are separate and must be identified explicitly; they are not the default dominant uncertainty for a normal ruler reading.

3) Calculations / intermediate steps
- Smallest division d = 1 mm → half-division a = d/2 = 0.5 mm.
- If uniform distribution within ±0.5 mm, standard uncertainty u = a/√3 = 0.5/√3 ≈ 0.29 mm. This quantifies the random uncertainty from resolution.

4) Why the correct answer is correct
- The main uncertainty when simply reading a length from a metre ruler is the unpredictable, irreproducible reading variation (resolution and human reading) — i.e., random uncertainty.

5) Why the other option is incorrect
- Systematic uncertainty would imply a consistent bias (e.g., ruler has wrong zero or is permanently stretched). Those are specific issues; they are not the typical uncertainty category for an ordinary single reading without evidence of bias.

6) Conclusion
- Therefore the most suitable category is Random uncertainty, which matches the provided answer.
